產品簡介：

ECM99-IE型電腦中頻治療儀由主機(含顯示器)、臺車、電極和輸出線組成。該機采用PC微機控制，圖形化友好界面，人機對話操作方式。具有8個雙向波輸出通道和2個配合藥物導入的離子導入通道，可以2-8路任意同步（處方、幅度）或異步工作，可同時對8個病人或8個部位進行治療。本儀器儲存130個處方，30個多步程序中頻電流療法、20個音頻電流療法、20個正弦調制中頻電流療法、30個脈沖調制中頻電流療法、30個干擾電流療法。本機可以在治療時建立病案，在建立病案的方式下治療，治療的病案可以打印輸出。本機還具有自行編制治療處方功能，容量不限，為臨床和科研提供廣闊的天地。

產品優勢：

1. 原始處方：存儲了公司理療專家顧問、發明人林士德的原始電子處方。

2. 安全性更高：通過了11項電磁兼容測試。

3. 同時治療人數或部位多：同時治療8個病人或8個部位。

4. 處方數多：130個儲存處方。

5. 具有自編處方功能，方便臨床研究、試驗。

6. 具有病案管理、打印功能。

7. 界面友好，具有輸出波形顯示等功能。

   基本參數：

1. 輸出通道：雙向波8路，離子導入2路。

2. 輸入功率：380VA。

3. 處方類型：多步程序、音頻電流、正弦調制、脈沖調制、靜態和動態干擾電流。

4. 外形尺寸（長×寬×高）：580mm×600mm×1180mm。

   重量：40kg。

Product Profile:

ECM99-IE computer IF therapeutic instrument is composed of host (including display), trolley, electrode and output line. The machine is controlled by PC, with friendly graphical interface and man-machine dialogue. It has 8 bidirectional wave output channels and 2 ion introduction channels cooperating with drug introduction. It can work synchronously (prescription, amplitude) or asynchronously in 2-8 channels, and can treat 8 patients or 8 sites simultaneously. The instrument stores 130 prescriptions, 30 multi-step procedures of frequency current therapy, 20 audio current therapy, 20 sinusoidal modulation of frequency current therapy, 30 pulse modulation of frequency current therapy, 30 interference current therapy. The machine can set up medical records during treatment, and treat them in the way of establishing medical records. The medical records of treatment can be printed out. The machine also has the function of self-compiling treatment prescription, and has unlimited capacity, which provides a wide field for clinical and scientific research.

Product advantages:

1. Original prescription: Store the original electronic prescription of Lindstein, the company's physiotherapy expert consultant and inventor.

2. Higher security: passed 11 EMC tests.

3. Number or location of patients treated at the same time: 8 patients or 8 sites treated at the same time.

4. More prescriptions: 130 stored prescriptions.

5. It has the function of self-compiling prescription and is convenient for clinical research and experiment.

6. It has the functions of medical record management and printing.

7. Friendly interface, with output waveform display and other functions.

Applicable disease (prescription):

Analgesic effects: periarthritis of shoulder, epicondylitis of humerus, cervical spondylosis, lumbar disc herniation, degenerative osteoarthritis, rheumatoid arthritis, rheumatoid arthritis, contusion, myofibritis, muscle strain, stenosing tenosynovitis, pelvic inflammatory disease, adnexitis, chronic pharyngolaryngitis, breast hyperplasia, sciatica, peripheral nerve injury, articular contracture, chronic anterior column Adenosis.

Improve local blood circulation and promote the dissipation of inflammation: periarthritis of shoulder, epicondylitis of humerus, cervical spondylosis, lumbar disc herniation, degenerative osteoarthritis, rheumatoid arthritis, rheumatoid arthritis, contusion, myofibritis, muscle strain, stenosing tenosynovitis, pelvic inflammation, appendix inflammation, chronic pharyngitis, mammary gland hyperplasia, sciatica, peripheral nerve injury Injury, joint contracture, chronic prostatitis, myositis, delayed union of fracture, Reynolds disease.

Softening scar release adhesion: scar, scar contracture, postoperative adhesion, intestinal adhesion, post-inflammation sclerosis, post-injection sclerosis, hematoma mechanization, stenosing tenosynovitis.

Excited nerve and muscle: Muscle dysfunction after nerve or muscle injury, disused muscle atrophy, postoperative intestinal paralysis, urinary retention, constipation, vocal cord paralysis, gastroptosis.

Product Certificate: Registration Certificate Number: Beijing Food and Drug Supervision Instrument (Quasi) No. 226235, 2014.

Basic parameters:

1. Output channel: 8 channels of bidirectional wave and 2 channels of iontophoresis.

2. Input power: 380VA.

3. Prescription types: multi-step program, audio current, sinusoidal modulation, pulse modulation, static and dynamic interference current.

4. Shape size (length * width * height): 580 mm * 600 mm * 1180 mm.

Weight: 40kg.
